6000m3/h RH<20% High Efficiency Pharmaceutical Industry Desiccant Dehumidifier
The best way to solve problems at the production of pharmaceutical products
In order to achieve all these goals, it is necessary to reach the optimum humidity during production and storage of products!
The problems of uncontrolled humidity during production and storage
The best solution to these problems is to remove excessive moisture by dessicant method during production and storage of pharmaceutical products. This is a smoother method of air drying, which ensures the optimum level of product humidity at low temperatures. It prevents development of bacteria and their spreading through the system of ventilation.
These tasks are solved by desiccant dehumidifiers of Fuda Company.
What is a desiccant dehumidifier?
A desiccant dehumidifier has no compressor and does not use a cold surface to extract the excess moisture from the air. Instead it has a desiccant wheel that absorbs the moisture from the air, in a similar way to a sponge.
When should you use a desiccant dehumidifier?
Desiccant-based systems are more economical than refrigeration systems at lower temperatures and lower moisture levels. Typically, a desiccant dehumidification system is utilized for applications below 45% RH down to 1% RH.
How does desiccant dehumidification work?
Desiccant dehumidifiers use a desiccant material, typically silica gel, which absorbs water vapour from the air. A fan draws air into the dehumidifier and passes it through a section of a slowly rotating wheel which holds desiccant which dries the air.
Specifications:
Main Parameters |
|
Model |
ZCB—6000 |
Total Process Airflow |
6000m3/h |
Fresh Airflow |
300 m3/h |
Recirculated Airflow |
5700 m3/h |
Rotor Regeneration Airflow |
2000m3/h |
Parameters of Output Air |
T=25℃ RH=20% |
Regeneration Power |
42kw |
The Power of Regeneration Fan |
1.5kw |
The Power of Blower |
5.5kw |
The Power of Driving Motor |
0.1kw |
Installed Power |
49.1kw |
Cooling Load |
232.6kw |
Power Supply |
3P/380V/50HZ |
User Friendly Automatic Interface Control System:
Production Workflow Chart:
We can make suitbale dehumidifying solution for you according to your requirements. If you are interest on our product, contact us now.
