Newly Designed Automatic Temperature and Humidity Control Industrial Desiccant Dehumidifier RH≤20%

Newly Designed Automatic Temperature and Humidity Control Industrial Desiccant Dehumidifier RH≤20%

Quick Details:

Dehumidifying Mode: Cooling combined with Wheel

Desiccant Rotor: Import

Desiccant Material: Silica Gel Wheel

Rated Process Airflow: 6000m³ /h

Supply Air Parameters: T≤20℃, RH≤20%

Dehumidification Efficiency: High

Installed Power: 49.1kw

Voltage: 380V, 3 phase, 50Hz or customized

Certification: ISO9001:2015

Features: Economical, energy-saving

Usage: Air temperature and humidity control

General Description:

Industrial Desiccant Wheel Dehumidifier removes humidity using both cooling coil and a desiccant wheel, so it can both control the humidity and temperature of the air independently in one package unit.

Operating Principles:

Supply Air Stream

Outside air is drawn into the unit using the supply fan. The warm, moist outside air first passes through filters and then the cooling coil where it is cooled. The air then goes through the desiccant wheel where the air is dehumidified and the temperature is raised. At last the air is delivered directly to the space or into an existing air handler.

Exhaust Air Stream

Exhaust air is used to provide energy recovery for the desiccant wheel and is drawn into the unit using the exhaust fan. The air filtered and then heated and humidified during the energy recovery process. The air is then heated while passing through the regeneration coil. The heated air removes the moisture that the desiccant wheel adsorbs from the process air stream.

Applications:

• War Industry, Scientific Research, Electric Power Transportation
• Lithium Battery Industry, Biotechnology Pharmaceutical Industry
• Chemical, Daily Chemical Industry, Food Beverage Industry
• Safety Glazing Material Industry, Tyre and Rubber Industry
• Medical Instrument, Vegetables Frozen, Precise Instrument
• Wood Goods, Shipbuilding Painting Industry, Kinds of Storage

Specifications:

Competitive Advantage:

• Import silica gel wheel
• A totally self contained unit
• PLC + HMI automatic control system
• Aluminum alloy frame, anti-cold bridge
• Body modularization design, foam injected double wall casing
• Process and reactivation air flow sectors are insulated
• Electric or steam heating or convert type can be available
• All operation parameters can be on-line observed, ensuring operation reliability
• High temperature safety thermostat cutout
• Electrical interlocking of fan motors, heaters and rotor driving

We can provide technical design and suitable dehumidifier according to your requirements.
